The 8 monitors can show or switch the single simultaneous or individual. PC selection via push buttons and IR remote control and the RS232. HE408M is very suitable for the place such as the professional photography company, home theater, meeting room or the Audio-visual display in the market. Used the latest HDMI1.3 specification and comply with the FULL HD 1080p.

Features:

1.Input 4 different sets of HDMI signals at the same time and extended through the CAT6 UTP cable. Doing different switch through 8 sets of monitors. The 8 monitors can show or switch the single simultaneous or individual.

2.Selected signal source and the signal output position by the push buttons, IR remote control or the RS‐232.

3.Built-in infrared receiver to pick up the signal.

4.Infrared remote distance farthest can reach two meter.

5.Provide the RS232 connect port, through the PCs to control the single source and the single output position.

6.The LED display the System connection status.

7.Module hardware design supports Plug and Play.

8.Used the latest HDMI1.3 specification and compatible down the lower specification. The digital single ascent to 36 bit. Degrade the image more outstanding.

9.Use the most senior display chip of ADI that own the highest compatibility.

10.Support the high resolution.
A.The PC single up to the UXGA ( 1600x1200 )@60Hz;
B. the HDMI resolution up to the 1080p ( 1920x1200 ).

11.The distance of the input HDMI cable can up to 30 meters.

12.The long distance receiver built-in adjustable knob revises the weakness of signal.

13.The below shows the resolution of the HE408 supported:
A. The short distance receiver(HR/PHR):720p/1080i@25m;1080p@15m.
B.The long distance receiver(HE100R) :720p/1080i@90m;1080p@70m.

14.Made in Taiwan
