PANIO KD04A 4-Port USB Dual VGA KVM Switch with Audio-TW
Pengiriman :
3 hari sejak pembayaran
Lokasi :
Sumatera Selatan
Update Terakhir :
19-08-2013 14:51
Dapatkan Spesifikasi Harga
PANIO KD04A 4-Port USB Dual VGA KVM Switch with Audio-TW Produk Terbaik dari
PANIO Information Company KVM,video&audio switch,extender,splitter
Detail Produk
| |
 |
PANIO KD04A 4-Port USB Dual VGA KVM Switch with Audio
4-port USB Dual VGA KVM switch with Audio supports Dual VGA monitors with the resolution up to 2048 x 1536. This KVM switch features USB & PS/2 Keyboard and mouse support, one 2-port USB 2.0 HUB and Audio function. KD04A allows you to control computers by pushing button, hot key. With the powerful function, KD04A is the best KVM switch to satisfy your demand of Dual Video connections. |
|
| |
 |
 |
Controls 4 dual-video enabled computers from a single console (keyboard/mouse) over USB connection by using standard USB cables and dual monitors.
|
|
Supports PS/2 keyboard/mouse and USB keyboard/mouse.
|
|
Compliant with USB Specification Revision 2.0 and USB Device Class Definition for HID Revision 1.11.
|
|
Four computers can share two USB downstream ports.
|
|
Supports two types of switching:
a. Push button on front panel
b. Hot keys on PS/2 and USB keyboard
|
|
LED display for easy status monitoring.
|
|
Supply Microsoft Intellimouse 3 ~ 5 Key Mouse & Microsoft Natural Keyboard Pro series.
|
|
Supports VGA interface.
|
|
Supports VGA resolution up to 2048 X 1536 @85Hz.
|
|
Supports Windows 98/98SE/2000/ME/XP/Vista/7, Linux, MAC OS9/OSX, SUNMICRO Solaris 8 or later.
|
|
Provide USB HUB switching in independent method or combination with the host switching (USB HUB Auto-Switch mode).
|
|
Provides audio switching in independent method.
|
|
Auto-Scan function (Time interval can be adjusted between 5-20 seconds when the Auto-Scan function is enabled).
|
|
Plug and Play (Windows 98/SE users might need your Windows CD to install the HID driver for USB keyboard/mouse.)
|
| |
| |
 |
| |
 |
| |
| |
 |
|
1 x KD04A |
|
8 x USB + VGA cable (1.8M) |
|
4 x USB to Audio cable |
|
1 x DC 5V 2A Power adaptor |
|
| |
| |
 |
| |
| Model No. |
KD04A |
| Number Of Computer Controlled |
4 |
| Selection Method |
Push Button/Hot Key |
| LEDs |
Host Selected LED (RED) |
| HUB Selected LED (Green) |
| Auto Switch & Auto Scan LED (Green) |
| Compliant with USB Version |
USB1.0 / USB1.1/ USB2.0 |
| Compliant with HID Version |
USB HID 1.11 |
| PC Connectors |
Video |
8 x VGA WUXGA male |
| USB |
4 x USB Type B female (For USB) |
| 4 x USB Type B female (For Audio) |
| Console port |
Video |
2 x VGA WUXGA female |
| Keyboard |
1 x PS/2 6 pin mini-DIN female |
| 1 x USB Type A female |
| Mouse |
1 x PS/2 6 pin mini-DIN female |
| 1 x USB Type A female |
| Microphone |
1 x Audio Jack Female (Pink) |
| Speaker |
1 x Audio Jack Female (Green) |
| USB Downstream ports |
2 x USB Type A female |
| Auto-Scan Interval |
5,10,15,20 sec |
| DDC, DDC2 monitor |
Yes(Max.Resolution:2048x1536 @85Hz) |
| Operating system supported |
Win 98/98SE/ME/2000/XP/Vista/7 |
| Mac OS9/X, Linux, Sun Micro OS |
| Cables Included |
4 sets of USB and VGA cable |
| 4 sets of specific USB - Audio cable |
| Cable Length |
1.8 Meter (USB/VGA cable) |
| 20 cm ( specific USB-Audio cable ) |
| Power |
By External Adaptor |
| Output Voltage |
5V |
| Output Current |
2A |
| Hot Pluggable |
Yes |
| Device driver |
No |
| Dimensions (L x W x H) |
269 x 81 x 44 mm |
| Unit Weight |
1073g |
|
| |
|
