Features:
1.Through the CAT6 UTP cable to extend the 8 groups HDMI signal synchronized.
2. All In One Cable:Different from the other extender the HE408 extend the HDMI signal only in one cable.
3. Suitable for surveillance system, DVR, Outdoors multimedia display, Digital display, Home appliance decorate ,Wiring, Door control,Projector extender and so on.
4. Full-featured HDMI switch that switching the different HDMI signal easily.
5. Module hardware design supports Plug and Play.There is no system compatibility issue.
6. PC selection via automatic and manual switch or remote control.
7. Scanning and browsing the channel of PC Power on automatic.
8. Receive the remote signal through the built-in IR receiver or External remote.
9. The LED display the System connection status.
10. Used the latest HDMI1.3 specification and compatible down the lower specification. The digital single ascent to 36 bit. Degrade the image more outstanding.
11. Use the most senior display chip of ADI8197 that own the highest compatibility.
12. Support the high resolution: 480i, 480p, 720p, 1080i, 1080p.
13. With Auto Scan function, the interval time is 20, 40, 60, 80 seconds.
14. Adjust the video quality through the built-in 8 parts electronic video adjustment.
15. There is a fine tune button on the long distance receiver that make the HDMI signal more clearly on the remote distance.
16.The below shows the resolution of the HE408 supported:
A. The short distance receiver:720p/1080i@
B.The long distance receiver :720p/1080i@
17. Made in Taiwan .
Remark: Suggest using UTP Cat6 cable, use other poor quality cable may lead to signal weaken that unable to achieve the satisfactory performance.
